Description

Syble Laser Barcode Reader – XB-2055

Performance Parameters:

  • Light Source: Utilizes a visible laser diode at 650nm for accurate and quick scanning.
  • Scan Rate: Impressive 300 scans per second, ensuring high-speed data capture.
  • Scanning Angle: Offers a wide scanning angle of ±55°±65°±30° (left & right, front & back, turn).
  • Scanning Width: Efficient scanning range of 30mm at the scanning window and 220mm at 200mm distance.
  • Scanning Type: Single-line scanning for straightforward and precise scanning.
  • Resolution: High resolution of 0.1mm (4mil) at PCS 0.9.
  • Depth of Scanning Field: 0-280mm (0.33mm.PCS 90%).
  • Print Contrast Minimum: 30%, ensuring minimum reflective difference (@650nm).
  • Indicator Light: LED DIODE for clear status indication.
  • Interface Support: Versatile connectivity with USB, PS2, RS232.

Physical Characteristics:

  • Voltage: DC 5V±1%.
  • Current: 85mA (Operating mode), 36mA (Quiescent current).
  • Dimensions: L83mm x W70mm x H172mm.
  • Weight: 205g (including cable).
  • USB Cable Length: 2M (Non-removable).
  • Housing Materials: Durable ABS PC.
  • Minimum Resolution: Capable of reading 3mil barcodes.

User Environment:

  • Operating Temperature: -10°~50°.
  • Storage Temperature: -40°~70°.
  • Operating Humidity: 5~95% relative humidity, non-condensing.
  • Environment Luminance: Up to 5,000 Lux Max (Fluorescence).
  • IP Level: IP54, offering dust and splash resistance.
  • Drop Specification: Withstands multiple 3m drops to concrete.

Safety and Compliance:

  • EMI/RFI: Compliant with FCC class A and CE.
  • Laser Safety: CDRH class 2 laser product.
  • Decode Capability: Can decode a variety of barcodes including UPC-A, UPC-E, EAN-13, EAN-8, Code 39, Code 128, and more.
  • Certificates: RoHS, CE, FC certified.

Why Choose the Syble XB-2055 Barcode Scanner?

The Syble XB-2055 is not just a scanner; it’s a robust tool designed to enhance the efficiency of your business operations. Whether it’s for inventory management, point of sale, or any other barcode scanning application, the XB-2055 delivers precision, speed, and reliability.
